Ecosys M4132idn

Product Features

Convenient and reliable, with a low total cost of ownership. That’s the ECOSYS M4132idn from Kyocera.

Award-winning ECOSYS technology combines with out-of-the-box functionality at print speeds up to 32 pages per minute and paper sizes up to A3. Advanced finishing options add professional looking output, while optional business applications further enhance the device’s capabilities with scalable solutions that expand workflow automation. Delivering a high level of functionality in a compact footprint, it’s the smart solution for businesses looking for a dependable, eco-friendly, and cost-conscious MFP.

https://youtu.be/1EyGZYd3jWo
Title: ECOSYS M4132idn
Output Speed: Up to 32/17 pages A4/A3 per minute. Duplex print speed: 29 page per minute, A4. Duplex copy speed: 29 page per minute, A4.
Processor: ARM Cortex-A9 Dual core 1.2GHz
Resolution: 1200 x 1200 dpi (print), 600 x 600 dpi (scan/copy)
Memory: Standard 1GB, max. 3GB
First Copy Time: Approx. 6.2 seconds or less (DP), Approx. 5.2 seconds or less (Platen Cover)
Time To Print First Page: Approx. 5.2 seconds or less
Warm Up Time: Approx. 20 seconds or less
Paper Handling Input: 500-sheet universal cassette + 100 sheet multi-purpose tray
Maximum Paper Handling Input: 1,600 sheets (with optional PF-471 Paper Feeder)
Paper Handling Output: Max. 280 sheets; 250 sheets face-down (main tray) plus 30 sheets (standard job separator tray)
Output Size: A3 (maximum)
Maximum Paper Handling Output: A3 (maximum)
Duplex: Standard (built-in)
Time to First Print: Approx. 5.2 seconds or less
HDD: Optional: HD-6 (32GB SSD); Optional: HD-7 (128GB SSD)
Printing: Standard Network black & white printing
Scanning: Scan-to-Email, Scan-to-FTP, Scan-to-SMB, Scan to USB Host, Network TWAIN, WIA , WSD scan
Scan Speed: 50 ipm (300 dpi, A4, b/w), 50 ipm (300 dpi, A4 colour)
Scan Features: Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Blank page skip
Faxing: Optional – Fax System 13
Zoom: 25–400% in 1% steps
Emulation: PRESCRIBE, PCL6 (5e/XL), KPDL3 (PostScript 3 compatible), PDF Direct Print, XPS Direct Print and Open XPS
Standard Interface: USB 2.0 (Hi-Speed), 2xUSB Host Interface, Gigabit Ethernet (10BaseT/100BaseTX/ 1000BaseT), optional Wi-Fi (IEEE 802.11b/g/n), 2 eKUIO slots, for optional internal print server or SSD hard disc & for optional fax system, Slot for optional SD Card, NFC tag
Control Panel: 177.8 mm (7 inch) full-colour touch panel display, speaker for job notification
Drum Life: 300,000 pages
Finishing Options: Optional: 500 Sheet Finisher DF-470*. Max. 500 sheets A4; 60–163 g/m2; A3, A4, A5, B5, Letter, Legal, Custom (98 x 148 to 297 x 432 mm), positions stapling up to 50 sheets A4 or 25 sheets A3. *Bridge unit AK-470 is required for the use of DF-470
Dimensions & Weight: (W x D x H) 590 x 590 x 688 mm (with standard Document Processor). Approx. 52 kg (with standard Document Processor)
Warranty: 3 year on-site warranty or up to 300,000 pages (whichever occurs first)
